Rent or Buy Chroma 63206A-1200-240 High Power DC Electronic Load, 1200V, 240A, 6kW



Tektronix Encore




Chroma 63206A-1200-240
High Power DC Electronic Load, 1200V, 240A, 6kW

Electronic Loads >> DC Electronic Loads, More than 3kW up to 10kW >> High Power DC Electronic Load, 1200V, 240A, 6kW
Rent Used Test Equipment
Manufacturer: Chroma
Model: 63206A-1200-240

Chroma 63206A-1200-240 High Power DC Electronic Load, 1200V, 240A, 6kW

Electronic Test and Measurement Equipment

Chroma 63206A-1200-240 High Power DC Electronic Load, 1200V, 240A, 6kW Product Datasheet Download Product Datasheet

Rent Test Equipment

Available Option Configurations

Config-01

  • A636000 - GPIB
  • A636000 - GPIB Interface
  • Available for Rental    GET QUOTE

Config-02

  • 11460 - SoftPanel
  • A636000 - GPIB
  • Available for Rental    GET QUOTE

Config-04

  • No Options Included
  • Available for Rental    GET QUOTE

Product Overview

RENT CHROMA 63206A-1200-240 Programmable DC Electronic Load



    The Chroma 63206A series high power electronic loads with digital signal microprocessor built in have the optimal speed and control performance designed for testing a wide range of power conversion products. The DC loads have unique user defined waveform (UDW) capability and external analog modulating input for simulating realworld, custom waveforms. The 63206A-1200-240 electronic DC loads also have overcurrent, overpower, and over temperature protections as well as over voltage and polarity reverse alarms to enhance product reliability.

    Each model of the Chroma 63206A-1200-240 has 3 power ranges so they can precisely measure the voltage and current in real time. The 300% peak overpower capability provides extra headroom for fault condition simulations in automotive batteries, fuel cells, and more. Its super high voltage (0.015%+0.015%F.S.) and current (0.04%+0.04%F.S.) measurement accuracy ensures the fidelity of results. The Chroma 63206A-1200-240 electronic loads operate in constant voltage, current, resistance, or power modes to satisfy a wide range of test requirements. When the need is for increased power, two or more loads can be run in parallel to achieve the desired load current.



Specifications for the Chroma 63206A-1200-240 Programmable DC Electronic load include:

  Low Mid High
Voltage    0-1200V
Current 0-24A 0-120A 0-240A
Power 0-6000W
Min Operating Voltage 2V@24A 10V@120A 20V@240A



See Datasheet for full specifications
