Rohde & Schwarz SMB100B
RF Signal Generator, 8 kHz to 1 GHz, 3 GHz or 6 GHz
Signal Generators >> Signal Generators Over 3 GHz, Up To 6 GHz >> RF Signal Generator, 8 kHz to 1 GHz, 3 GHz or 6 GHz
Model: SMB100B
CLICK TO ENLARGE |
|
Download Product Datasheet
Product Overview
RENT ROHDE & SCHWARZ SMB100B RF Signal Generator (Call for Availability)
The Rohde & Schwarz SMB100B RF signal generator is all about performance and versatility in a small footprint. Outstanding spectral purity and very high output power combined with comprehensive functionality and very simple operation are just some of the impressive features. The SMB100B covers a frequency range from 8 kHz to 1 GHz, 3 GHz or 6 GHz. Thanks to its innovative synthesizer design, the Rohde & Schwarz SMB100B has very low SSB phase and wideband noise and excellent suppression of nonharmonic signal components.
Since the Rohde & Schwarz SMB100B provides very high output power, no external amplifier is required downstream. This simplifies the test setup and results in high absolute level accuracy. The SMB100B has a minimum specified power of –127 dBm as standard (for f > 10 MHz). With its specified maximum adjustable power of +26 dBm (1 MHz < f ≤ 6 GHz), it has a very wide dynamic range of 153 dB. The Rohde & Schwarz SMB100B RF Signal Generator is an ideal choice for a wide range of applications in R&D, production, service and maintenance where a good price/performance ratio is also a key factor.
Specifications for the ROHDE & SCHWARZ SMB100B RF Signal Generator Include:
| Frequency Range | 8 kHz to 1, 3, or 6 GHz |
| SSB phase noise | < –126 dBc, –132 dBc (typ.) |
| Harmonics | < –30 dBc |
| rise/fall time | 10% to 90% of RF amplitude, f > 80 MHz |
See Datasheet for full specifications
